Lighting for polytunnel

Discussion in 'Poly-Tunnel Gardening' started by madmick, Jun 13, 2011.

  1. madmick

    madmick Gardener

    Joined:
    May 20, 2011
    Messages:
    174
    Occupation:
    Retired
    Location:
    Hull East Yorks
    Ratings:
    +25
    Hi everyone anyone got any ideas about lighting in a polytunnel to extend growing season ? or am I just being over-enthusiastic (hope I spelled it right) My wife saw something on countryfile but didnt take a lot of notice Thanks Mick

  2. PeterS

    PeterS Total Gardener

    Joined:
    Mar 18, 2005
    Messages:
    6,662
    Gender:
    Male
    Occupation:
    Retired
    Location:
    N Yorks
    Ratings:
    +4,013
    Madmick - it can be done, but wouldn't be practical. I grow some plants under lights in both a special light-box and also in my house.

    The key thing about light is the light level. Because our eyes adapt automatically, we are not very good at judging light levels. So I have a light meter. On a sunny day in summer the level can be 25,000 lux (a measure of light intensity). Inside your sitting room at night with the lights on, the level might typically be 50 lux. Now thats is a big difference. In a brightly lit office it might be 500 lux.

    Sources quote the minimum for any reasonable growth is 3,000 lux. What that means is that you would need 6 times as many fluorescent lights in your polytunnel as you would find in a brightly lit office.

    [​IMG]
    I have a light box, shown above, where I can get plants to grow and flower. The light level at the top of the plants is 10,000 lux, and to get this level I use 3 three foot long fluorescent tubes over a growbag tray. I also have to have the lights very close to the plants as light levels fall away with distance and I also enclose it in a white box with doors at the front to stop any light escaping.

    It costs about £6 a month to run and I keep it in the house to make use of the heat. On that scale it is quite practical and great fun. I have germinated summer flowering plant seeds in November and had them in flower by early January. Its especially good for raising early plants from seed and for taking cuttings over winter. As I said it could be done on the scale of a polytunnel it would be very expensive. :D

    • Like Like x 2
    • *dim*

      *dim* Head Gardener

      Joined:
      Jun 26, 2011
      Messages:
      3,548
      Location:
      Cambridge
      Ratings:
      +1,593
      • Like Like x 1
      • PeterS

        PeterS Total Gardener

        Joined:
        Mar 18, 2005
        Messages:
        6,662
        Gender:
        Male
        Occupation:
        Retired
        Location:
        N Yorks
        Ratings:
        +4,013
        Dim - interesting video. LED lights are potentially excellent as grow lights - but they are very expensive to buy. The lights shown cost 60$ for 13 watts. Now they may give out twice as much light per watt of power as fluorescent tubes, but they can cost up to 5 to 10 times as much to buy.

        As I said on another thread about grow lights, there are many ways of delivering the right amount of the right type of light, but eventually it comes down to which is the cheapest way.

        • Like Like x 1
        • Richards in the shed

          Richards in the shed Apprentice Gardener

          Joined:
          Dec 14, 2011
          Messages:
          5
          Ratings:
          +0
          How about getting a load of those little LED pushlights from the £1 shop - you get three in a pack. Take the back off, wire them all up in series, attatch to a length of wood about 1" wide and attatch this to the underside of a piece of guttering. Wire up to a switch connected to a battery. Maybe connect to a light sensitive switch so that it comes on as soon as sun sets. Either use two batteries - one to charge while the other is in use or wire up a couple of cheapy solar panels (Maplin £12) about 2 watts at 12 volts.

          How about using an old paygo mobile phone, put a light sensitive switch against the screen and encase it in a box so if you call that mobile the screen lights up switching on your growlights, watering system or maybe a cctv camera?

        • madmick

          madmick Gardener

          Joined:
          May 20, 2011
          Messages:
          174
          Occupation:
          Retired
          Location:
          Hull East Yorks
          Ratings:
          +25
          Wow Richard I think you need to get out a bit more

        • lazydog

          lazydog Know nothing but willing to learn

          Joined:
          Jun 30, 2011
          Messages:
          790
          Gender:
          Male
          Occupation:
          waiting to win the Lotto
          Location:
          Black Country Nr Dudley
          Ratings:
          +641
          1thing IMO that makes growing your own food so enjoyable is eating what you can fresh whilst in season,it is not really worth trying to simulate nature it can be done and is regularly by the growers in professional systems and people growing certain crops that sell by the gramme :loll:

          • Like Like x 2
          • Phil A

            Phil A Guest

            Ratings:
            +0
            That put an amusing scenario into my head, setting up a hydroponics system in the attic & waiting for plod to detect it with their thermal cameras.

            Imagine how embarrased they would be when they busted your Tomato farm:heehee:

            • Like Like x 2
            • lazydog

              lazydog Know nothing but willing to learn

              Joined:
              Jun 30, 2011
              Messages:
              790
              Gender:
              Male
              Occupation:
              waiting to win the Lotto
              Location:
              Black Country Nr Dudley
              Ratings:
              +641
              • Like Like x 2
              • Phil A

                Phil A Guest

                Ratings:
                +0
                I did get asked by my neighbour if the Tomato in the kitchen was a pot plant.:heehee:

                I have a friend who planted a real pot plant in the flower bed at the front of Sherbourne police station. It was there all summer:thumbsup: Police walking past it everyday:heehee:
